Introduction
AWS SAM (Serverless Application Model) is an open-source framework from AWS that helps developers build, test, and deploy serverless applications easily.
It simplifies working with AWS serverless services like:
- AWS Lambda
- API Gateway
- DynamoDB
- Step Functions
- EventBridge
It provides a way to define infrastructure as code (IaC) and manage deployments through the AWS SAM CLI.
AWS SAM mainly has two important parts:
- SAM Transform Templates
- AWS SAM CLI
1. SAM Transform Templates
AWS SAM templates are infrastructure-as-code templates used to define serverless applications.
SAM templates are built on top of AWS CloudFormation, which means SAM extends CloudFormation by adding serverless-specific resources and simplifying deployment.
Instead of manually creating:
- Lambda functions
- API Gateway endpoints
- Permissions
- Event triggers
we can define everything inside one SAM template.
Lambda and Events
A Lambda function cannot work by itself. It needs an event source to trigger it.
Common Lambda triggers:
- API Gateway requests
- S3 uploads
- SNS messages
- SQS messages
- EventBridge events
Inside a SAM template, we define:
- Lambda function
- Event source that triggers the Lambda function
This makes managing serverless applications easier.
AWS SAM Serverless Resource Types
AWS SAM provides 8 main serverless resource types:
AWS::Serverless::Function
Creates Lambda functions.
AWS::Serverless::API
Creates REST APIs using API Gateway.
AWS::Serverless::HttpApi
Creates HTTP APIs using API Gateway.
AWS::Serverless::SimpleTable
Creates DynamoDB tables.
AWS::Serverless::LayerVersion
Creates Lambda layers.
AWS::Serverless::Application
Allows reuse of serverless applications.
AWS::Serverless::StateMachine
Creates AWS Step Functions workflows.
AWS::Serverless::Connector
Creates permissions and connections between resources.
Lambda Event Sources Supported by SAM
Lambda functions can be triggered by:
- Amazon S3
- Amazon SNS
- Amazon Kinesis
- Amazon DynamoDB Streams
- Amazon SQS
- API Gateway
- HTTP API
- Scheduled Events
- Amazon Cognito
- Amazon EventBridge
SAM allows these integrations to be defined directly inside the template.
2. AWS SAM CLI
AWS SAM CLI is a command-line tool used to:
serverless applications.
AWS SAM Local
SAM Local allows developers to test serverless applications locally before deploying.
It supports:
- Unit testing
- Functional testing
- Debugging
Run APIs Locally
Command:
sam local start-api
or
aws sam start-api
This runs API Gateway and Lambda locally.
Invoke Lambda Locally
Command:
sam local invoke
This invokes Lambda locally by simulating:
- A service sending an event
- Lambda receiving and processing the event
Generate Mock Events
Command:
sam local generate-event
Generates sample events from AWS services.
Examples:
- S3 event
- SQS event
- API Gateway event
AWS SAM Accelerate
SAM Accelerate improves the development workflow by reducing deployment time.
It includes:
SAM Build
Command:
sam build
Features:
- Parallel builds
- Incremental builds
- Temporary layers
SAM build only rebuilds changed resources instead of rebuilding everything.
SAM Sync
Command:
sam sync
SAM Sync updates changes quickly without a full deployment.
It is mainly used for development.
It watches changed files and updates AWS resources faster.
SAM Logs
Command:
sam logs
Allows developers to view CloudWatch logs from the terminal.
Features:
- Aggregated logs
- Log filtering
- Trace information
SAM Deploy Flow
The deployment process:
flowchart LR
A[Template YAML File<br/>SAM Template] --> B[S3<br/>Upload Lambda Code<br/>and Artifacts]
A --> C[ECR<br/>Amazon Elastic Container Registry<br/>Upload Container Images]
B --> D[Create CloudFormation<br/>Change Set]
C --> D
D --> E[Deploy to CloudFormation Stack]
E --> F[AWS Resources Created<br/>Lambda<br/>API Gateway<br/>DynamoDB<br/>Other Serverless Resources]
SAM Deploy
Command:
sam deploy
Deploys the serverless application to AWS.
Before deploying:
sam build
SAM packages application artifacts and uploads them to:
depending on the application type.
AWS SAM Pipeline
AWS SAM provides tools to create CI/CD pipelines for serverless applications.
It automatically generates:
- AWS resources
- Permissions
- Pipeline configuration
Pipeline Bootstrap
Command:
sam pipeline bootstrap
Creates AWS environment resources and permissions required for the pipeline.
Pipeline Init
Command:
sam pipeline init
Generates pipeline configuration.
Flow:
sam pipeline bootstrap
|
↓
sam pipeline init
Serverless Application Repository Patterns
AWS provides reusable serverless patterns.
There are more than 186 AWS SAM patterns available.
These patterns help developers quickly create common architectures.
SAM Config File
AWS SAM supports:
samconfig.toml
This file stores default values for SAM commands.
Example:
Instead of repeatedly passing deployment parameters, store them inside the config file.
Best Practice: Let SAM Name Your Resources
Avoid manually hardcoding resource names.
Example:
Avoid:
FunctionName: MyApplicationLambda
Allow SAM and CloudFormation to generate resource names.
Benefits:
- Avoid naming conflicts
- Easier deployments
- Better environment management
- Works better with multiple stages
